Products and services

Design Build

We have the Sales Staff, Engineers, and Detailers ready to start your Steel Building Project from the ground up. We will start with your ideas and convert them to a full set of Engineered Sealed construction drawings and follow up with manufacturing your Steel Building.

Permit Drawings

We can provide you with a full set of Permit Drawings ready to submit to your city or local government. Just let us know what you need and we will get it designed.

Construction Drawings

All of our buildings come with a full set of Engineered Sealed construction drawings.

Approval Drawings

We can provide a full set of Approval Drawings for your project. This will allow you or your customer to review your building design prior to production.

Foundation Design

We can provide you with a design for your concrete foundation. We will use your soil information combined with our building reactions to design your concrete foundation design.  Ask your sales representative for details.

Windstorm Requirements

We can design your building package to conform to your local windstorm requirements. Local requirements are supplied by the purchaser.

Metal Roof and Wall Panels

PBR (36″ COVERAGE) – Purlin Bearing Leg

  The PBR panel’s deep rib creates an even shadowed appearance. The Major ribs are 1-¼” in depth and are on 12″ centers. The area between the major ribs is reinforced with two minor ribs for added strength and stability. This panel can be used for roof, walls, liner, mansard and soffit panel.

PBU (36″ COVERAGE) – Purlin Bearing Leg

  The PBU panel has shallow ¾” ribs on 6″ centers and is available for walls, liner, partitions and soffit panels.

PBA (36″ COVERAGE) – Purlin Bearing Leg

  The PBA panel’s ribs are 1-1/8″ in depth and are on 12″ centers, creating a smooth shadow line with its semi-concealed fasteners. This panel is especially useful in wall and liner applications.

369 (36″ COVERAGE)

  The 369 panel’s ribs are ¾” in depth and are on 9″ centers. This panel can be used for roof, walls and liner panel.

TS-324 (24″ COVERAGE x 3″ HIGH)

  The TS-324 (TRAPEZOIDAL SYSTEM) standing seam panel is designed to last. Innovative clips add stability while allowing for thermal expansion and contraction along with a patented seaming system that is designed to handle even the most stringent uplift requirements.
This panel is available in Galvalume Plus and Kynar 500 finishes.

VS-216 (16″ COVERAGE x 2″ HIGH)

  The VS-216 (VERTICAL SYSTEM) standing seam panel provides superior wind and weather protection under all roof loading conditions. The seam geometry and seaming methods virtually assure that your installed roof will perform as it was designed at minimum cost.
This panel is available in Galvalume Plus and Kynar 500 finishes.
